Silicone Rubber Self-fusing Tape Manufacturer




Description:

Self-fusing Silicone Tape is a convenient, ready to use tape which can be used to make airtight and waterproof seals on many types of materials and applications including electrical connections, hoses, and cables and to reduce vibration of hand tools. It is tear, abrasion, and UV resistant and it withstands exposure to fuel, water, oil, acids, and many solvents. It is a class H Insulator. This product is designed to seal hoses and leaky plumbing, insulate electrical connections, wrap hand tool handles. Direction for use note: 1. Remove any excess dirt, oil, etc. from repair area and clean hands with hand cleaners or soap and water before starting the repair. 2. Remove package and peel 1-2 inches of liner from the tape. 3. Press the exposed tape firmly to the surface to be repaired, making sure to completely overlap the first wrap over itself while at the same time stretching the tape.




Features:

·  Operating temperature: -60-180℃
·  Standard color: Red,Yellow,Blue,Green
·  Flame retardant grade: V0(UL94)
·  Hardness shore: 53A

Technical Data:

Properties	Typical Data	Test Method
Tensile Strength	≥3.5Mpa	ASTM D 412
Elongation at break	≥300%	ASTM D 412
Dielectric Strength	≥25KV	ASTM D 149
Aurohension	13.7N/cm（typical data）	GB/T 20631.2-2006
Water absorption	0.35%	ASTM D 570
Volume Resistivity	≥1.0×10140.cm	ASTM D 876

Dimensions:

Size(mm)              Width(mm)			Standard Package
				(M/Roll)
			Thickness(mm)
25*0.5		25                                                                       0.5                             5/Customized
25*0.8		25                                                                       0.8                                                 5/Customized
50*0.5		50                                                                       0.5                                                 5/Customized
50*0.7		50                                                                       0.7                                                 5/Customized
50*0.8		50                                                                       0.8                                                 5/Customized
50*1.8		50                                                                       1.8                                                 5/Customized
80*1.8		80                                                                       1.8                                                 5/Customized
100*1.8		100                                                                     1.8                                                 5/Customized

Note: Other dimensions or package can be customized as request.
